Straight Centrifugal Pump, Cast Iron, 1-1/4" x 1" FPT Ports with #204, 4 GPM Hydraulic Motor, 60 GPM MAX, 100 PSI @ 4600 RPM MAX

FMC-HYD-204: For Pressure Compensating Closed Center (John Deer), or Open Centered Systems rated at 4-13 GPM.

These cast iron straight centrifugal frame mounted pumps are driven by a close coupled hydraulic motor. The hydraulic motors have built in reverse check valves to prevent seal damage due to impeller coasting and reverse rotation. Each motor also has an integral needle valve to by-pass excess hydraulic fluid on open center systems. Valox Impeller; Cast Iron optional. Stainless shafts and wear rings. Standard Viton® mechanical seals.

Available E-Coated with silcarbide seal for salt brine.
Viton® is a registered trademark of DuPont Performance Elastomers.
