TurboDrop® Variable Rate Spray Tip Nozzle, 05 Orifice, 110 ° , Single Fan

TurboDrop® Variable Rate Nozzles (110° Flat Fan) will cover the range of three to four standard TurboDrop® nozzle sizes. The flow rate increases more rapidly with an increase in pressure, making variable rate nozzles useful in covering wider speed ranges or providing on-the-go variable rate application. As with all ag spray nozzles, it is important to match droplet size to the application type. The TwinFan Variable Rate (Twin 110° Flat Fans) will provide a smaller droplet size spectrum compared to the single fan version, as well as deliver dual spray coverage.

3 Times Flow Rate at Constant Speed (variable rate applications)
3 Times Speed Range at Constant GPA Rate (variable speed applications)
Flow Tolerance ± 10% to 15%
Use Flow Control Systems with Meters for Best Accuracy
Operate Above 45 PSI for Best Pattern
Tabulations Based On Spraying Water at 70° F.

Pressure Range: 40 to 140 PSI
Recommended Boom Height: 18" to 36" (on 20" centers)
Material of Construction: Polyacetal & EPDM

Manufacturer:

SKU: GTTDVR05

Save!

10% on 50

$28.50 / EA

Qty:

i h

TurboDrop® Variable Rate Spray Tip Nozzle, 05 Orifice, 110 ° , Single Fan

Shipping costs will be invoiced at time of shipment for all orders shipping to locations outside of the contiguous United States including Hawaii and Alaska. If you require a freight quote, please call us at 1-888-677-5054.

Additional Information
