115-Volt DC Fuel Transfer Pump, 15 GPM, Manual Nozzle

600 Series • Heavy Duty • UL Listed

Fill-rite's FR600 Series of heavy-duty fuel transfer pumps have been an industry standard for years, offering trouble-free performance for many fuel handling applications. Designed to be lightweight, sturdy, and compact, these 115-volt fuel pumps are built for long-lasting service under demanding operating conditions. For use with Gasoline & Diesel fuels. Max flowrate is 15 GPM.

The FR610H fuel pump features a 3/4" FPT inlet and a 1/4 Hp, 115-volt explosion-proof motor with thermal overload protection. Pump kit comes complete with a 3/4" manual fuel nozzle, 3/4" x 12' fuel hose, 1" telescoping (20" – 34") steel suction pipe, 15' power cable, and a built-in check valve and 20-mesh strainer.

Specifications:

Type: Positive Displacement (Rotary Vane)
Pump Body Material: Cast Iron
Inlet/Outlet Size: 3/4" FPT
Mounting Size/Type: 2" MPT
Bung Max Flowrate: 15 GPM
Duty Cycle: 30 Mins.
Motor Power: 1/4 Hp
Voltage: 115 Volt AC
Max Amp Draw: 20 Amps
Max Operating/Discharge Pressure: 16 PSI
Operating Temperature Range: -17° to 104° F
Suction Lift: 8'
Warranty: Limited Lifetime – 1 Year on Accessories

Manufacturer:

SKU: FR610H

VIEW CATALOG PAGE E0276

$569.00 / EA
