    Actuated Ball Valve, Tru-Torq, Poly w/ Poly Ball, 2" Flanged, 2-Way, Full Port, EH2, On-Off, 12/24-Volt, **1.5 Second Close

    KZValve Tru-Torq ball valves offer high flow performance with premium-quality components. Tru-Torq series ball valves are designed to mount directly to KZValve EH series actuators for reliable power during operation and are actuator-ready for any application. Tru-Torq ball valves feature mounting bosses molded directly into the valve body, reducing mounting time and maintaining undisturbed torque specifications of the ball and end caps. This 2-way motorized ball valve features 2" full-port Flanged end caps that allow quick, easy installation of the valve into a variety of inline systems.

    Valve is rated to 150 psi working pressure at @ 70° F.

    Technical Specs:
    • Type: Tru-Torq Ball Valve
    • Style: On/Off
    • Port Size: 2"
    • Body Material: Polypropylene
    • Ball/Disc Material: Polypropylene
    • Seat Material: Virgin PTFE
    • Flow Direction: 2-way
    • Flow: Full Port
    • Manifold: No
    • Normally Open/Closed: Closed
    • Operation: 12/24-Volt DC
    • Actuation Type: Electric
    • Actuation: 1.5 seconds
    • Connection Type: 2" Flanged
    • Max Working Pressure: 150 psi

    ** Close time is 1.5 seconds for both 12 & 24V
    Manufacturer: KZValves
    SKU: KZT2I22-10AYS-BF1
    $794.00 / EA
